| Model
No. |
ULAP R14 |
| Laptop Type |
Rugged
laptop |
| Waterproof Grade |
IP65/MIL-STD-810G |
| Dimensions |
356*269*37mm |
| Weight |
2.935kg |
| Material |
PC+10%GF |
| OS |
Windows
10 home 64bits |
| Bands |
2G:
GSM850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz |
| 4G: FDD-LTE:B1/B3/B5/B7/B8/B20/B28A,
TDD-LTE:B38/B40/B41 |
| CPU |
8th
Generation KBL-R Intel Core i5-8250U
(i7-8550U optional for OEM) |
| GPU |
Intel
UHD Graphics 620 |
| RAM |
8GB
DDR4L (16GB optional for OEM) |
| SSD |
256GB
SSD (512GB optional for OEM) |
| Speaker |
8Ω/1W
x2 |
| Microphone |
Digital
microphone x2 |
| Optical Drive |
N/A |
| Display |
14
inch 16:9 display screen, 1920*1080px, 700cd/㎡ |
| Pointing Device |
Touchpad |
| Camera |
Single
camera, 2.0MP front camera |
| WiFi |
IEEE802.11
a/b/g/n/ac, support 2.4GHz/5GHz dual band wifi |
| GPS Module |
U-blox
NEO-7 module |
| BT Version |
V4.2
(BLE) class1, transmission distance: 10 meters |
| NFC |
NXP
13.56MHz, 4cm, ISO/IEC 14443A/B/18092/mifare etc. |
| Fingerprint Unlock |
SPI
fingreprint sensor (power on login) |
| Sensor |
Hall
sensor |
| I/O
Interfaces |
3x
USB 3.0 |
| 1x USB 2.0 |
| 1x 3.5mm audio jack |
| 1x HDMI |
| 1x SD Card slot |
| 1x SIM slot |
| 1x DC (19V,3.42A) |
| 1x DB9 RS232/RS485 |
| 2x RJ45 Port |
| 1x POGO PIN |
| Battery |
Built-in
2000mAh/7.4V+ removable 6300mAh/7.4V polymer battery |
| Working Time |
6.5
hours video playing |
| Product Reliability |
Anti-drop:
80cm composite wood floors |
| Operation temperature: ‘-10 °C to 50 °C |
| Storage temperature: ’-20 °C to 60 °C |
| Humidity: 95% Non-Condensing |
| Color |
Black |
| Accessories |
Power
adapter x 1 |
| User manual x 1 |
