| BASIC INFO |
| Model No. |
UNIWA
V810 |
| Operating system |
Android
12 |
| Dimension |
254*152*21.5mm |
| Weight |
820g
(with battery) |
| Material |
ABS/PC |
| Color |
Black,
yellow |
| Language |
Multi-languages |
| HARDWARE |
| Display |
8.0
inch dragontrail IPS capacitive touch screen, 1280*800px (1000 nit screen
optional) |
| Processor |
MT6765
Helio P35 octa core, up to 2.3GHz; GPU: PowerVR Rogue GE8320 |
| RAM |
4GB RAM |
| ROM |
64GB ROM,
support TF card up to 128GB maximally |
| Camera |
Double
cameras, front camera 5MP, Rear camera 13MP with flashlight |
| Battery |
Built-in
3.85V/8000mAh Li-Po battery |
| Sensor |
3D
accelerometer, E-compass, Proximity sensor, Light sensor |
| Speaker |
2030
speaker |
| Buttons |
Vol+/-, SCAN
button, PTT button, Power on/off，2 custom buttons |
| NETWORK & CONNECTIVITY |
| Band |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1700/1900/2100MHz, TD-SCDMA
B34/39 |
| 4G: FDD-LTE
B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B, TDD-LTE B34/38/39/40/41 |
| WiFi |
IEEE802.11 a/b/g/n/ac,
support 2.4GHz/5.8GHz dual band WiFi |
| BT |
V5.0 |
| GNSS |
Support
GPS, BDS, GLONASS |
| I/O INTERFACES |
| SIM Slots |
*2
or SIM+TF card |
| USB Type-C Port |
*1 |
| 5V DC-IN |
*1 |
| 3.5mm audio jack |
*1 |
| Pogo Pin |
*1 |
| FEATURES |
| NFC |
Support, NXP 557 chip, 13.56MHz |
| Fast Charging |
18W
fast charging |
| OTG Function |
Support |
| OPTIONS |
| HF RFID Reader |
Optional,
840-960MHz, group reading speed >50PCS/sec, distance≤3M |
| Barcode scanning |
Optional,
Zebra 4710, Honeywell 5703 or CM30 |
| Fingerprint reader |
Optional,
Small fingerprint sensor or industrial fingerprint |
| RELIABILITY |
| Waterproof |
IP68 |
| Temperature |
Operating:
-10°C~50°C, Storage: -20℃~70℃ |
| Humidity |
5%RH-95%RH,
non-condensing |
| Drop-proof |
MIL-STD-810G,
1.5m drops |
| Rolling Test |
1000-time
0.5m rolling test |
| ACCESSORIES |
| USB Cable |
*1 |
| Charger |
*1 |
| User manual |
*1 |
| Hand Strap |
Optional |
| Charging dock |
Optional |
